Table: Voice Equipment Window Display Options
| Display Option |
Possible Values |
Effect |
Default |
| Equipment:
|
card
Note:
Information about SPs is displayed only if the "card" option is specified in this field.
|
The card option displays the channels in groups of 6, corresponding to the 6 channels per IVC6 card. It also displays the card: card number, O.S. Index, function, and state. |
blank |
| channel |
The channel option displays the channels in numeric order without division by card. |
| group |
The group option displays the channels in the specified group in group order, without division by card. |
| Number:
|
One or more channel, card, or group numbers. You can specify:
- A single card, channel, or group number, for example, 1
- A range of card, channel, or group numbers, for example, 0–4
- A combination of the two, for example, 2,5–9,11
- The word all for all cards, channels, or groups
|
Only the cards, channels, or group specified are displayed on the Voice Equipment window. |
all |
| Type:
|
SP T1 TR |
The equipment type displays in the Function field. Only the type specified displays in the Voice Equipment window. The type is displayed as part of the Class field when Report by Card is specified and as part of the Type field when Report by Group is specified. |
blank |
| State:
|
broken foos hwoos manoos inserv |
These states are explained in the table for Field Definitions: Display Voice Equipment Window. Only the cards or channels in the state specified are displayed on the Voice Equipment window. This field is not available if the Equipment field is set to group. |
blank (for all states) |
| Service:
|
Single service name: could be AUDIX for INTUITY AUDIX Voice Messaging. Press F2 (Choices) for a complete list of possible applications. |
Only the channels in the service specified are displayed on the Voice Equipment window. This field is not available if the Equipment field is set to card or group. |
blank (for all services) |
