Field Name
|
Valid Input
|
Description/Procedure
|
|
LWC Reception
|
spe (default) or audix
|
If you enter audix
here, you must enter the AUDIX name on the AUDIX-MSA Nodes Names screen
in the AUDIX Name field.
|
|
LWC Activation
|
n
|
|
|
CDR Privacy
|
n
|
|
|
|
y (default) or n
|
|
|
Per Button Ring Control
|
n
|
|
|
Bridged Call Alerting
|
n
|
|
|
Switchhook Flash
|
y
|
|
|
Ignore Rotary Digits
|
n
|
|
|
H.320 Conversion
|
n
|
|
| Service Link Mode |
as-needed |
|
| Multimedia Mode |
basic |
|
| AUDIX Name |
|
Leave blank (default). However, if the LWC Reception field is audix,
you must enter the AUDIX name on the AUDIX-MSA Nodes Names screen. |
| Messaging Server Name |
|
Leave blank. |
|
MWI Served User Type
|
|
If the INTUITY AUDIX system will support multiple
switches in a QSIG network, enter qsig-mwi.
|
|
Coverage Msg Retrieval
|
n
|
|
|
Auto Answer
|
none
|
|
|
Data Restriction
|
n (default) or y
|
|
|
Call Waiting Indication
|
y (default) or n
|
|
|
Att. Call Waiting Indication
|
y (default) or n
|
|
|
Distinctive Audible Alert
|
y (default) or n
|
|
|
Adjunct Supervision
|
y
|
|
|
Per Station CPN - Send
Calling Number
|
Leave blank
|
|
|
Coverage After Forwarding
|
Use default
|
|
|
Direct IP-IP Audio Connections
|
y (default) or n
|
Allows direct audio connections between IP endpoints.
Valid entries are y and n. Enter y to save
on bandwidth resources and improve sound quality of voice over IP
(VoIP) transmissions.
|
|
IP Audio Hairpinning
|
y (default) or n
|
Allows IP endpoints to be connected through
the IP circuit pack on the switch. Allowable entries are y
and n. Enter y to allow IP endpoints to be connected
through the IP circuit pack on the switch in IP format.
|
